PCB Layout
PCB Layout Support for Fabrication and Assembly
PCB Layout Process
We first review your schematics, component data, board size, and production needs. Our engineers use Altium Designer, Cadence Allegro, and Mentor PADS to place components and route the PCB.
During PCB layout, we check the layer stack-up, impedance, differential pairs, signal paths, power, heat, and assembly needs. We also perform DFM and DFA checks. These checks help us find design problems before production.
After you approve the layout, we prepare the production files. These files may include Gerber or ODB++, NC drill files, pick-and-place files, fabrication drawings, and assembly drawings. They help move your project from PCB layout to PCB fabrication and assembly.
PCB Layout Software & Platform
Capabilities
Design Platforms
- Altium Designer
- Cadence Allegro
- Mentor PADS
- OrCAD Capture
- AutoCAD
- Polar impedance tools
- Customer-supplied design files
Layout Capabilities
- Rigid PCB layout
- Flexible PCB layout
- Rigid-flex PCB layout
- HDI and microvia design
- RF and microwave routing
- High-speed digital routing
- Analog and mixed-signal layout
- Controlled-impedance routing
- Differential-pair routing
- Length matching
- BGA and fine-pitch component layout
- Blind and buried via structures
- SMT and THT component integration
Engineering Services
- Schematic capture
- PCB component placement
- Manual and interactive routing
- Stack-up coordination
- Impedance planning
- Design for manufacturability review
- Design for assembly review
- Gerber data preparation
- Pick-and-place data preparation
- Fabrication and assembly drawing preparation
- Existing PCB layout modification
Design Verification
- Netlist comparison
- Clearance and spacing review
- Annular ring review
- Trace width and via review
- Mechanical fit checking
- Board outline and keep-out review
- Differential-pair and length-matching review
- Power and ground connection checks
- Open and short risk checks
- Silkscreen and component overlap review
- Fabrication and assembly constraint review
Manufacturing Outputs
- Gerber or ODB++ files
- NC drill files
- IPC-356 netlist
- Fabrication drawings
- Assembly drawings
- Pick-and-place files
- BOM coordination files
- Native PCB layout files
- 3D mechanical exchange files
- Layer stack-up information
- Controlled-impedance requirements
- Production release package
Why Choose Topline Circuit?
- PCB fabrication and assembly from one supplier
- Engineering support from file review to production
- DFM checks before fabrication and assembly
- Support for prototypes and production orders
- Component sourcing for full or partial BOMs
- AOI, X-ray, ICT, and functional testing based on project needs
- Clear updates during production
Certifications
Our certifications support consistent quality management and PCB manufacturing controls.
ISO 9001
Quality management system certification
UL materials
PCB Layout Support for Faster Production
Our engineers review your files before PCB layout starts. We check the schematics, component data, board size, stack-up, and production needs.
During layout, we consider PCB fabrication and assembly needs. We check component placement, routing, impedance, clearances, and design rules. This helps find problems before production.
Our support includes:
- File review before PCB layout
- DFM and DFA checks
- Stack-up and impedance planning
- Support for complex PCB designs
- Production file preparation
- Support from layout to fabrication and assembly
